通過式旋轉清洗機:中小型零件清洗好幫手
來源:http://www.taijiaomusic.cn/ 時間: 2025-07-09 瀏覽次數: 0
機械制造行業里的通過式旋轉清洗機,用處挺廣,像交通運輸、石油化工、輕工產品生產以及設備維修等行業的中小型零件,都能用它來清洗。另外,在零件電鍍前、熱處理前后還有產品組裝前,需要清洗的時候,它也能滿足要求。
The through type rotary cleaning machine in the mechanical manufacturing industry has a wide range of uses. It can be used to clean small and medium-sized parts in industries such as transportation, petrochemicals, light industry production, and equipment maintenance. In addition, it can also meet the requirements for cleaning before electroplating, heat treatment, and product assembly of parts.
在一些比較繁重的清洗工作中,通過式旋轉清洗機的優勢很明顯。它的工作道理不復雜:要清洗的零件表面有油污、臟東西這些雜質,清洗機噴出來的水射流會產生機械力,再加上熱量和金屬洗滌劑的作用,這些雜質就會慢慢變濕、變軟,然后和零件分開,最后被清洗液帶走,這樣就把零件洗干凈了。
In some heavy cleaning tasks, the advantages of the rotary cleaning machine are very obvious. Its working principle is not complicated: the surface of the parts to be cleaned has impurities such as oil stains and dirt. The water jet sprayed by the cleaning machine will generate mechanical force, coupled with heat and the action of metal detergent. These impurities will slowly become wet and soft, then separate from the parts, and finally be carried away by the cleaning solution, thus cleaning the parts thoroughly.
從整體來看,通過式旋轉清洗機包含好幾個系統,有加熱及溫控系統、過濾系統、輸送系統、噴霧系統、干燥系統和電氣控制系統。它的機身主要由車架、車蓋和水箱組成,整個機器結構緊湊,樣子好看,功能也很齊全。
As a whole, the pass through rotary cleaning machine includes several systems, including heating and temperature control system, filtering system, conveying system, spray system, drying system and electrical control system. Its body is mainly composed of a frame, a hood, and a water tank. The entire machine has a compact structure, a beautiful appearance, and complete functions.
機身是用焊接型鋼做的,很結實。車蓋是可以拆下來的,主要材料是鋼板,裝在車架的各個框架結構上,這樣在維修的時候,裝卸起來都很方便。水箱有內外兩層,都是用鋼板焊接而成的,耐用性不錯。
The body is made of welded steel, which is very sturdy. The car cover can be removed, mainly made of steel plate, and installed on various frame structures of the frame, making it easy to install and remove during maintenance. The water tank has two layers, inside and outside, both made of welded steel plates, with good durability.
加熱及溫控系統的主要作用,就是在設備運行的時候給清洗液加熱。一般來說,這個系統是用電加熱管來加熱水基清洗液的。清洗液的溫度能從室溫調到 60℃,而且是可以連續調節的,這樣就能滿足不同情況下的清洗需求了。比如有的零件油污比較頑固,就可以把溫度調得高一點,讓清洗效果更好;有的零件材質特殊,不能用太高溫度的清洗液,那就可以調低一些。
The main function of the heating and temperature control system is to heat the cleaning solution during equipment operation. Generally speaking, this system uses electric heating tubes to heat water-based cleaning solutions. The temperature of the cleaning solution can be adjusted from room temperature to 60 ℃, and it can be continuously adjusted to meet the cleaning needs in different situations. For example, if some parts have stubborn oil stains, the temperature can be raised slightly to improve the cleaning effect; Some parts are made of special materials and cannot be cleaned with too high a temperature, so they can be lowered slightly.
有了這些系統和結構的配合,通過式旋轉清洗機才能穩定地工作,把各種中小型零件清洗干凈,滿足不同行業的生產需求。
With the coordination of these systems and structures, the rotary cleaning machine can work stably, clean various small and medium-sized parts, and meet the production needs of different industries.
本文由通過式清洗機友情奉獻.更多有關的知識請點擊:http://www.taijiaomusic.cn我們將會對您提出的疑問進行詳細的解答,歡迎您登錄網站留言.
This article is a friendly contribution from a high-pressure deburring cleaning machine For more information, please click: http://www.taijiaomusic.cn We will provide detailed answers to your questions. You are welcome to log in to our website and leave a message
