According to the operation instructions of the single tank ultrasonic cleaning machine, the operation steps are as follows. First, configure the cleaning solution first, add an appropriate amount of clean water and detergent into the cleaning tank to ensure that the cleaning solution can soak the electrical circuit to be cleaned and stir it. Second, turn on the single tank ultrasonic cleaning machine, adjust the temperature control button and set the cleaning solution temperature. The specific temperature should be determined according to the active temperature of the cleaning agent. Third, after the cleaning fluid reaches the set temperature, put the electrical circuit into the cleaning tank to ensure that all the circuits are filled with cleaning fluid. Fourth, adjust the cleaning power and cleaning time, and press the cleaning button.

當單槽式超聲波清洗機清洗時間一到，人們需關閉超聲波電源，停止清洗，將溫度控制按鈕復位，停止恒溫控制。隨后將電氣線路從清洗槽中取出，并且利用清水進行沖洗，將線路表面的殘留污垢和清洗液清洗干凈。再然后是將清洗槽中的污水排放干凈并且清潔清洗槽，清洗過后要將清洗槽擦干。為了保護單槽式超聲波清洗機，在不使用它時應該將其放在干凈、干燥的場所，防止其電路受潮。

When the cleaning time of the single tank ultrasonic cleaning machine comes, people need to turn off the ultrasonic power supply, stop cleaning, reset the temperature control button and stop the constant temperature control. Then take out the electrical circuit from the cleaning tank and wash it with clean water to clean the residual dirt and cleaning solution on the circuit surface. Then discharge the sewage in the cleaning tank and clean the cleaning tank. After cleaning, wipe the cleaning tank dry. In order to protect the single tank ultrasonic cleaning machine, it should be placed in a clean and dry place when it is not used to prevent its circuit from moisture.

單槽式超聲波清洗機的工作原理是怎樣的呢？下面為大家介紹下其工作的主要環節和步驟，超聲波清洗機如何工作的原理及知識。超聲波清洗機原理主要是將換能器，將功率超聲頻源的聲能，并且要轉換成機械振動，通過清洗槽壁使之將槽子中的清洗液輻射到超聲波。由于受到輻射的超聲波，使之槽內液體中的微氣泡能夠在聲波的作用下從而保持振動。 超聲波清洗機—強勁超聲波清洗機

What is the working principle of single tank ultrasonic cleaning machine? The following will introduce the main links and steps of its work, the principle and knowledge of how the ultrasonic cleaning machine works. The principle of ultrasonic cleaning machine is mainly to convert the transducer to the sound energy of the power ultrasonic frequency source and convert it into mechanical vibration, so as to radiate the cleaning liquid in the tank to ultrasonic through the cleaning tank wall. Due to the radiated ultrasonic, the microbubbles in the liquid in the tank can keep vibrating under the action of sound waves. Ultrasonic cleaning machine - powerful ultrasonic cleaning machine

不使用--參考圖片組合.jpg當聲壓或者聲強受到壓力到達一定程度時候，氣泡會迅速膨脹，然后又突然閉合。在這段過程中，氣泡閉合的瞬間產生沖擊波，使氣泡周圍產生1012-1013pa的壓力及局調溫，這種超聲波空化所產生的巨大壓力能破壞不溶性污物而使他們分化于溶液中，蒸汽型空化對污垢的直接反復沖擊。

Not used -- refer to picture combination. JPG when the sound pressure or sound intensity is under pressure to a certain extent, the bubble will expand rapidly and then close suddenly. In this process, the shock wave is generated at the moment of bubble closure, resulting in 1012-1013 PA pressure and local temperature regulation around the bubble. The huge pressure generated by ultrasonic cavitation can destroy insoluble dirt and make them differentiate into solution. The direct reverse impact of steam cavitation on dirt.

清洗范圍

Cleaning range

適用于電子、機械、汽車、電鍍、化纖、光學、清洗線路板、磁芯、油嘴、汽車零配件、汽車維修、電鍍五金工具、化纖噴絲板、光學鏡片、軸承、工具、餐具、醫療器械、精密五金、鐘表零件、金銀飾品、電子元件等。

It is applicable to electronics, machinery, automobile, electroplating, chemical fiber, optics, cleaning circuit board, magnetic core, nozzle, automobile spare parts, automobile maintenance, electroplating hardware tools, chemical fiber spinneret, optical lens, bearings, tools, tableware, medical instruments, precision hardware, clock parts, gold and silver jewelry, electronic components, etc.

優點

advantage

清洗效果好、效率高、、成本低、清洗效果平均

Good cleaning effect, high efficiency, environmental protection, low cost and average cleaning effect

規格資料編輯

Specification data editing

1. 內槽尺寸：（超聲波）長*寬*深：L500*W400*D500mm

1. Inner groove size: (ultrasonic) length * width * depth: L500 * W400 * d500mm

2. 外型尺寸：長*寬*深：L680*W540*D720mm

2. Overall dimension: length * width * depth: L680 * w540 * d720mm

3.外體鋼材：1.2mm厚度Nissan#304不銹鋼片

3. External steel: 1.2mm thick nissan#304 stainless steel sheet

4. 內槽鋼板：2.0mm厚度Nissan #316不銹鋼片

4. Inner groove steel plate: 2.0mm thick Nissan #316 stainless steel sheet

5.超音波換能器數量：24枚

5. Number of ultrasonic transducers: 24

6.振動面鋼板：底部安裝,電鍍硬鉻

6. Vibrating surface steel plate: installed at the bottom and plated with hard chromium

7.加熱功率：安裝三塊1500鑄鋁發熱板

7. Heating power: install three 1500 cast aluminum heating plates

8.超聲波時間控制：配備進口控制器

8. Ultrasonic time control: equipped with imported controller

9.超音波信號發生器：外置式功率可調發聲器

9. Ultrasonic signal generator: external power adjustable sounder

10.超音波訊號線：屏蔽式訊號線,6米

10. Ultrasonic signal line: shielded signal line, 6M

11.超音波電源要求：AC220V 6A

11. Ultrasonic power requirements: AC220V 6A

12.發熱電源要求：AC220V 30A

12. Heating power requirements: AC220V 30A
